Overview
These are SuperATV’s cube light mounting brackets for the Polaris RZR XP 1000 and XP Turbo. They clamp to the factory A-pillars and give you a solid place for a pair of cube lights at the front corners of the cage. You can order the brackets alone or with two lights.
Which RZR it fits
- RZR XP 1000 and RZR XP 4 1000, 2014 to 2023
- RZR XP Turbo, 2016 to 2021
- RZR XP 4 Turbo, 2017 to 2021
- RZR XP Turbo S, 2018 to 2021
- RZR XP 4 Turbo S, 2019 to 2021
Other RZR models are not listed for these brackets. SuperATV also publishes which of its own windshields, doors and enclosures the brackets work with, by part number.
Compatible: FDWS-P-RZR1K-001, FDWS-P-RZR1K-002, FWS01-001, FWS-P-RZR-1K-001, FWS-P-RZR1K-002, HWS-P-RZR1K-001, HWS-P-RZRXPTS, WS-P-RZR1K-001, WS-P-RZR1K-002, WS-P-RZR1K-002-V, WS-P-RZR1K-V, DOOR-P-RZR1K-003, DOOR–P-RZRXP-001 and SE-P-RZRXP-001 (you may need to adjust the straps).
Not compatible with these SuperATV windshields: FDGWS-P-RZR1K, FDGW-P-RZRT, GWS-P-RZRXP-001-S, GWS-P-RZRXP-002, GWS-P-RZRXP-003, HWS-P-RZRXP and PFWS-P-RZR1K.
Brackets only or brackets with lights
The Cube Lights option is “None” or “Qty 2”. Choose “None” if you already own cube lights and only need somewhere to put them. Choose “Qty 2” if you are starting from nothing: you get the two lights described above with their harness and switch. For other lights to put on the brackets, see pod and cube lights.
More parts for this machine: Polaris RZR accessories.
Features
- Brackets: two mounting clamps and brackets
- Cube Lights option, "Qty 2": two 12 W cube lights in clear white, 1,920 raw lumens per light, 4 OSRAM 3 W LEDs per light, 1 amp draw at 12 V per light, IP67, working temperature -40°F to 140°F, with a wiring harness and rocker switch
Tech Specs
| Material | 1/8 inch steel, reinforced with gussets |
|---|---|
| Finish | Black powder coat |
| Mounting Type | To the OEM A-pillars, in 2 different positions |
Installation
The brackets clamp to the A-pillars with the supplied hardware, and SuperATV includes instructions. Decide on the position before you start. With a windshield, the brackets mount outside the cage. Without one, you can mount them inside the A-pillars, where they are tucked away from trees and rocks on tight trails.
FAQs
Will they work with my windshield?
It depends on the windshield. SuperATV lists compatible and not compatible part numbers, shown above. For a windshield from another maker there is no published answer, so check the clearance at the A-pillar.
Can I mount them inside the cage?
Yes, if you do not run a windshield. SuperATV says the brackets mount inside the A-pillars in that case, and outside the cage when you have a windshield.
Do the brackets come with lights?
Only if you pick "Qty 2" under Cube Lights. With "None" you get the brackets, clamps, hardware and instructions.
What are they made of?
1/8 inch steel with a black powder coat.
